Robot water jet cutting operation skills, water jet cutting use skills, practical knowledge of water jet cutting

I hope you understand the techniques used in robotic water jet cutting by reading this article, apply them to practice, and master them thoroughly.

1: Robot water jet cutting speed: If cutting thicker materials, water back occurs, please reduce the speed, or increase the pressure, or replace the orifice with a larger aperture.

2: Uneven cutting gap: Please replace the orifice, or observe the current fluctuation of high-pressure water.

3: Cost control: part of the cost of robotic water jet cutting is the ultra-high pressure intensifier pump. Please turn off the ultra-high pressure intensifier pump and vacuum adsorption system when not in use.

4: When the precision of water jet cutting round holes is not high: For small round holes or other forms of holes, please adjust the parameters, and reduce the cutting speed.

5: Operating habits: Please try to use the simple operation box to operate, it is simple and safe.

6: Efficient mold replacement: one person can replace molds with cranes or lifting systems.

7: Water quality treatment: Please observe and replace the water filter element and softened water additives in time. Good water quality can extend the life of other parts such as orifices and reduce the frequency of maintenance.

8: Noise problem: simple operators wear earmuffs and goggles.

9: Automatic cycle function: calculate the time, it will be more convenient to set the automatic cycle function.

10: Vacuum adsorption system clogging problem: install a cleanable waste box between the workbench and the vacuum adsorption system, which will solve the clogging problem of the vacuum adsorption system.

The above is related to the introduction of robot water jet cutting operation skills, water jet cutting use skills, and practical knowledge of water jet cutting. If you want to know more, please consult us.
