What is the accuracy of robotic water jet cutting?

The accuracy of the robot in the water jet cutting workstation is generally ±0.05mm-±0.06mm. Depending on the brand of the robot, the accuracy is also different, but the effect is not significant. The accuracy of the water jet cutting is generally about ±0.1mm. The working life and quality of the nozzle are different, which will cause the thickness of the water column to be different, so the dimensional accuracy of the cut parts will be about ±0.1mm. This accuracy can fully meet the standard in the automotive interior industry and other industries, so there is no need to worry about accuracy.

How thick waterjet can cut?

The thickness of the material for water cutting depends on the material itself. Metal materials can generally be cut 0-150mm thick, and non-metallic materials can be cut up to 50mm thick. Special attention should be paid to tempered glass not to use water jet cutting, but water jet cutting can be done before tempering, and tempering treatment is performed after cutting.

 The waterjet cutting of car interiors does not need to add abrasives, but hard materials need to add abrasives, such as stone, metal, glass, etc. The abrasive selection is generally 60 mesh to 120 mesh, which means the thickness of the abrasive , How to choose the abrasive? The 60-mesh abrasive cutting speed is fast, but the cutting surface is slightly rough, and the 120-mesh abrasive cutting speed is slower, but the cutting surface is smooth. Customers can choose according to actual cutting requirements.

How wide is the robot water jet cutting gap?

Pure water cutting for car interiors generally does not use focus tube, only orifice. The Inner diameter of the nozzle is generally 0.17mm-0.25mm. Pure water cutting cuts soft materials. The cutting gap is about 0.2mm-0.8mm. For cutting hard materials such as metals, abrasives and focus tubes need to be added. The orifice diameter is generally 0.33mm, the nozzle diameter is generally 1.07mm, and the cutting gap is generally about 0.8mm-1.3mm.

How loud is the noise of the robotic water cutting studio?

The noise of robotic water cutting is generally expressed in decibels, which is approximately below 80 decibels, but it is difficult for ordinary people to understand how much noise is 80 decibels? We can give an example to explain. Normal office conversation is 60 decibels. 80 decibels can be described as quarrels. It is slightly noisy, but it will not harm the human body. However, it is recommended that the staff wear earmuffs. Now that the robotic water cutting machine adopts a closed structure, the noise has been reduced a lot. When the equipment is running, the operator can normally hear the conversation. .
