Now robotic waterjet cutting machine has become the new favorite in processing fields, more and more people buy and understand robotic workstation.In the waterjet robots cost, replacing the waterjet consumables is one of the factors that need to be considered when calculating the cutting cost,like the orifice.Robotic arms cutting is divided into abrasive cutting and pure water cutting.Win-Win robotic waterjet cutting system mostly use KMT cutting head,here are some commonly used KMT orifices.

20448625,0.004"(.102);05063847,0.007"(.178);05112537,0.008"(.203);05084504,0.009"(.229);05077029,0.010"(.254);05101753,0.011"(.279);05077300,0.012"(.305);05136098,0.013"(.330);05077037,0.014"(.356);80075781,0.015"(.381);05121512,0.016"(.406);05114905,0.018"(.457);80086663,0.019"(.482);05114897,0.020"(.508).

Sapphire Orifice,for Abrasive Cutting,60K,used in Robotic Waterjet Trimming Autoline I and II.

The types of pump it is suitable for are NeoLine,SL-IV 100hp Dual Topworks,SL-IV 15hp - 60hp,SL-IV 75hp - 200hp,SL-IV Plus 100hp Dual Topworks,SL-IV Plus 15hp - 60hp,SL-IV Plus 75hp - 200hp,SL-V 100hp Dual Topworks,SL-V 15hp - 60hp,SL-V 75hp - 200hp,SL-VI 15hp - 60hp,SL-VI 75hp - 200hp and TriLine,rated pressure compatibility is 60000 psi.

There are these models and sizes for you to choose:

05109079,0.007"(.178);05109087,0.008"(.203);05109095,0.009"(.229);05109103,0.010"(.254);05109111,0.011"(.279);05109129,0.012"(.305);20412569,0.013"(.330);05109137,0.014"(.356);20448541,0.016"(.406);05114913,0.018"(.457);80086671,0.019"(.482);05114921,0.020"(.508).

Diamond Orifice,for Pure Waterjet Robot Water Only Cutting,60K.

The types of pump it is suitable for are NeoLine,SL-IV 100hp Dual Topworks,SL-IV 15hp - 60hp,SL-IV 75hp - 200hp,SL-IV Plus 100hp Dual Topworks,SL-IV Plus 15hp - 60hp,SL-IV Plus 75hp - 200hp,SL-V 100hp Dual Topworks,SL-V 15hp - 60hp,SL-V 75hp - 200hp,SL-VI 15hp - 60hp,SL-VI 75hp - 200hp and TriLine,rated pressure compatibility is 60000 psi.

There are these models and sizes for you to choose:

49888852,0.003"(.076);49888860,0.004"(.102);49888878,0.005"(.127);49888886,0.006"(.152);49888894,0.007"(.178);49888902,0.008"(.203);49888910,0.009"(.229);49888928,0.010"(.254);49888936,0.012"(.305);49836786,0.013"(.330);49888944,0.014"(.356);49888951,0.015"(.381);4988969,0.016"(.406);49888977,0.018"(.457);20436198,0.019"(.483);49888985,0.020"(.508);49888993,0.022"(.559).

The types of pump it is suitable for are NeoLine,SL-IV 100hp Dual Topworks,SL-IV 15hp - 60hp,SL-IV 75hp - 200hp,SL-IV Plus 100hp Dual Topworks,SL-IV Plus 15hp - 60hp,SL-IV Plus 75hp - 200hp,SL-V 100hp Dual Topworks,SL-V 15hp - 60hp,SL-V 75hp - 200hp,SL-VI 15hp - 60hp,SL-VI 75hp - 200hp and TriLine,rated pressure compatibility is 60000 psi.

There are these models and sizes for you to choose:

A2260003,0.003"(.076);A2260004,0.004"(.102);A2260005,0.005"(.152);A2260006,0.006"(.178);A2260007,0.007"(.178);A2260008,0.008"(.203);A2260009,0.009"(.229);A2260010,0.010"(.254);A2260011,0.011"(.279);A2260012,0.012"(.305);A2260013,0.013"(.330);A2260014,0.014"(.356);A2260015,0.015"(.381);A2260016,0.016"(.406);A2260018,0.018"(.457);A2260019,0.019"(.483);A2260020,0.020"(.508);A2260022,0.022"(.559).

Diamond Orifice,for Automation Waterjet Robot Abrasive & Water Only Cutting,Autoline PRO series,90K.

The types of pump it is suitable for are PRO I,PRO II and PRO III,rated pressure compatibility is 90000 psi.

There are these models and sizes for you to choose:

20481704,0.004"(.102);20481705,0.005"(.127);20481706,0.006"(.152);20481707,0.007"(.178);20481708,0.008"(.203);20481709,0.009"(.229);20481710,0.010"(.254);20481711,0.011"(.279);20481712,0.012"(.305);20481713,0.013"(.330);20481714,0.014"(.356);20481715,0.015"(.381);20481716,0.016"(.406);20481717,0.017"(.432);20481718,0.018"(.457);20481719,0.019"(.483);20481720,0.020"(.508);20481721,0.021"(.533);20481722,0.022"(.559).

Diamond Orifice, Food Grade, for Robot Water Jet Cell Water Only Cutting,60K.

The types of pump it is suitable for are NeoLine,SL-IV 100hp Dual Topworks,SL-IV 15hp - 60hp,SL-IV 75hp - 200hp,SL-IV Plus 100hp Dual Topworks,SL-IV Plus 15hp - 60hp,SL-IV Plus 75hp - 200hp,SL-V 100hp Dual Topworks,SL-V 15hp - 60hp,SL-V 75hp - 200hp,SL-VI 15hp - 60hp,SL-VI 75hp - 200hp and TriLine,rated pressure compatibility is 35000 psi,55000 psi or 60000 psi.

There are these models and sizes for you to choose:

72113688,0.005"(.152);72132350,0.006"(.178);72113753,0.007"(.178),3/8-24 Thread;72113680,0.007"(.178);72132358,0.008"(.203);72136231,0.009"(.229);72136249,0.010"(.254);72136256,0.011"(.279).

Diamond Orifice Assembly,for 6Axis Robotic Waterjet Abrasive Cutting,prealigned,Autoline PRO, 90K.Includes wear insert,2 O-rings and set screw.

The types of pump it is suitable for are PRO I,PRO II and PRO III,rated pressure compatibility is 90000 psi.

There are these models and sizes for you to choose:

20496208,0.008";20496210,0.010";20496211,0.011";20496214,0.014"

The service life of 3D Robot Waterjet Cutting Cell Orifice is related to the following points.

1. Related to water quality

The high-pressure water is very fast, so a little impurities will cause a lot of impact. Generally speaking, pure water is the best protection for orifice. Therefore, if you want to protect the robotic waterjet system, a water filter is also necessary.

2. Related to orifice quality

There are many types of orifice, such as sapphire, ruby, emerald, diamond, etc., mainly due to the different texture of the water outlet, and the material here is destined to the quality of the orifice, such as the diamond orifice has the highest hardness, the use time is dozens of general sapphire  ruby hundreds of times, so the most important thing is related to the material of the orifice.

Win-Win orifice is made of exquisite stainless steel jacket and silicon crystal inlaid with orifices. The product has fine workmanship, high gloss, high temperature resistance, high pressure resistance, high hardness, and works under high pressure robot cutting for a long time every day. The quality is safe and reliable.
