Hydraulic Pump Parts Sealing head 10106417 1.13 plunger units

• Part Name：Sealing head 1.13 plunger units
• Part Number：10106417
• Technical tips：A conventional water jet sealing head can be used for ten months to one year, of course, it also includes Sealing head 10106417. If it is less than this time, please check the reasons: 1. Whether the water quality is qualified, good water quality will extend the use time of many parts , the unqualified water generally contains physical particles and magnesium, calcium, etc., physical particles can make the dynamic hard seal failure. The front end of the sealing head and the surface of the low pressure poppet retainer are very important. If the particles in the water are caught between the sealing head and the low pressure poppet retainer In the meantime, for a long time, this surface will be damaged, causing damage to the sealing head. 2. Is the pressure stable? The impact force of the stable pressure on the sealing head is uniform, which will reduce the pressure difference and protect the sealing head. 3: The quality and material of the outlet body, high pressure valve seat and low pressure poppet pin, these parts and the sealing head are matched with each other. Too hard or too soft materials will cause damage to the sealing head. The design requirements need to have reasonable material hardness requirements and meet the technical requirements, which is more reasonable.
