Waterjet high pressure fitting straight hand valve

• Introduction：As waterjet high pressure fittings, waterjet HP Hand Valve is generally used in robotic waterjet workstations. The ultra-high pressure waterjet intensifier pump can provide three robot arms to work at the same time. If the three robot arms are controlled separately, this needs to be added at the front end of each manipulator UHP Hand Valve, when only one robot arm is required to work, please close the other two Straight Hand Valves or straight hand valve , so that you can switch to work as one robot arm work. The manual shut-off valve works reliably and is easy to operate. After installing the manual shut-off valve, Operation and maintenance will be more convenient.
• Parameters：Part number: 10079259(1/4), 10078863 (3/8), 10078889 (9/16) Pressure: 4200bar Details: This UHP Hand Valve bears a pressure of 4200bar. The specifications of the ports connected at both ends are: 1/4, 3/8, 9/16, which are based on the specifications of the high pressure pipe. The structure is Straight Hand Valve, clockwise Close the HP Hand Valve, counterclockwise is to open the manual UHP hand valve, Straight Hand Valve is a type of Waterjet High Pressure Fittings, if you need to know more about Waterjet High Pressure Fittings, please contact us, we will send you a complete set of information for your reference.
